System on Modules

Phytec propose toute a gamme de modules processors à base of derniers processors imx8 de NXP

Advantages with phyCORE modules from PHYTEC:

  • Support of all processor signals
  • Compact and cost-optimized layout
  • RAM + Flash fully integrated
  • Schematic reviews
  • Individual PCBs possible
  • Including customized board support package






phyCORE®-AM62Px

  • 4x Cortex-A53 @ 1.4GHz
  • GPU: With up to 50 GFLOPS
  • Up to 3 displays simultaneously
  • 35mmx50mm

phyCORE®-AM62Lx FPSC

  • dual-core Cortex-A53
  • best price performance ratio
  • Scalable & compatible thanks to FPSC
  • space- and cost-saving
New: SOM Standard i.MX 8M Plus, compatible with all SOM Phytec

phyCORE®-i.MX 8M Plus FPSC

  • Quad core 1,8GHz Cortex-A53
  • incl. Vision System
  • NPU with up to 2,3 TOPS
  • Pin compatible: Standard FPSC 24.0

phyCORE®-i.MX 95
FPSC

  • Hexa-Core 2,0 GHz Cortex-55
  • Pin compatible: Standard FPSC 24.0
  • Up to 3 displays simultaneously
  • Simple FTGA soldering technology

phyCORE®-i.MX 91/93

  • Cortex®-M33 MCU (i.MX 93)
  • Reduce your recruitment costs
  • Low energy consumption
  • 36 mm x 36 mm x 3 mm

phyCORE®-STM32MP13x

  • STM32MP13x, Cortex-A7
  • Reduce your recruitment costs
  • Low energy consumption
  • 36 mm x 36 mm x 3 mm

phyCORE®-AM68x/TDA4x

  • For image processing and AI
  • Display connector
  • 50 GFlops graphics
  • Industrial interfaces

phyCORE®-AM64x FPGA

  • For time-critical tasks
  • Arm® Cortex®-A53/-R5F/-M4F
  • Lattice ECP5 FPGA
  • 4x Ethernet interfaces

phyCORE®-AM64x

  • 4x Industrial Ethernet
  • EtherCAT
  • Supports ePWM, eCAP, and eQEP
  • DDR4 with inline ECC

phyCORE®-AM62Ax

  • Up to Quad ARM® Cortex®-A53
  • Cortex®-M4F MCU up to 400 MHz
  • Vision Processing Accelerators
  • C7 Deep Learning Accelerator

phyCORE®-AM62x

  • Quad core Arm Cortex-A53
  • Dual display support
  • GPU support
  • PRU

phyCORE®-i.MX 8M Plus

  • Quad core 1,8GHz Cortex-A53
  • Incl. Vision system
  • NPU with up to 2,3 TOPS
  • Industrial networking

phyCORE®-i.MX 8M
Mini / Nano

  • Low cost from € 44
  • power saving
  • shock/vibration resistant
  • MIPI DSI to Flatlink converter

phyCORE®-i.MX 8M

  • Multimedia performance
  • Wi-Fi / BLE 4.2 onboard
  • shock/vibration resistant
  • Savings by saving the connectors

phyCORE®-i.MX 8

  • highest computing power
  • maximum feature expansion
  • Audio subsystem
  • 3,3 V, little circuit complexity

phyCORE®-i.MX 8X

  • SE050 NXP Security Chip
  • energy efficient
  • 3x CAN / CAN FD
  • HiFi 4 audio DSP

phyCORE®-STM32MP15x

  • Cortex-M4 for real time
  • Vivante OpenGL ES2.0 graphics
  • up to 2x CAN FD
  • MIPI DSI / Parallel 18-bit / HDMI-CEC

phyCORE®-
i.MX 6UL / ULL

  • Reduce your recruitment costs
  • Low energy consumption
  • 36 mm x 36 mm x 3 mm
  • available in rolls

phyCORE®-i.MX 6

  • scalable performance
  • 2 camera interfaces
  • Voice control engine
  • flexibility through soldering or plug-in technology

phyCORE®-AM57x

  • Embedded vision engine
  • industrial ethernet
  • Dual C66x DSP
  • 6x audio McASP

phyCORE®-AM65x

  • up to 6x Industrial Ethernet
  • High performance graphics
  • MIPI DSI, LVDS
  • Wi-Fi on board

phyCORE®-i.MX 7

  • Real-time application
  • 2x Gigabit Ethernet
  • SLC NAND or eMMC
  • MIPI DSI / Parallel 24-bit

phyCORE®-AM335x

  • inexpensive and robust
  • industrial ethernet
  • 3D / 2D GPU
  • flexibility through soldering or plug-in technology

phyCORE®-MPC567x / 5777

  • Single/dual core PowerPC
  • Xilinx Artix7 FPGA
  • FlexCAN / FlexRay
  • 2x RS-232

phyCORE®-TC399

  • up to 6 TriCore processors
  • GB Ethernet
  • 4x CAN
  • HW security module
